Grow Table Agricultural Nursery Two Tier Vertical Farming Mobile Vertical Grow Rack Systems
Application: commercial indoor,agricultural projects for nursery, flowers and vegetable cultivation, etc.
Description:
The track-type multi-layer mobile seedbed makes full use of the greenhouse space and height, better expands the greenhouse space, improves the ground utilization rate, uniform layer load, strong load capacity (90tg/m2), overall easy management, convenient movement, and With locking function and anti-turnover device.Can be customized according to the different needs of customers and different profile styles!
Why choose the seedbed?
• Labor savings and cost-effective
• Versatile system
• An entire acre or more can be watered automatically and efficiently
• Plants are watered evenly, reducing losses due to poor watering practices
• Plants can be fertilized as they are being watered
• Floors are dry, avoiding accidents
• Compatible with many computer control systems
Specification:
| No. | Items | Parameters |
| 1 | Name | Vertical Grow Racks for Indoor Farming |
| 2 | Size(L, W) | 5.5x15ft, 5x10ft, 4*8ft, 2*4ft or customized |
| 3 | Tray Height | 12.5cm/ 7.5cm/ 3cm |
| 4 | Compositon | End trays, middle tray and division trays |
| 5 | Fittings | Valve sump |
| 6 | UV protective | Yes |
| 7 | Metal Support | Available |
| 8 | Support Height | 70cm |
| 9 | Material | Plastic ABS |
| 10 | Color | Black, Gray, White or customized |
| 11 | Application | For grow seedlings, flowers, vegetables, crops |
Details:
2.Plants can be fertilized as they are being watered
| Standard Size | 2ft / 3ft / 4ft / 5ft / 6ft width with any length(can be customized) |
| Standarder Height | About 70cm , height adjustable 8-10cm (can be customized) |
| Rolling Distance | 30-60cm each side |
| Product Material | Food grade ABS tray , hot dip galvanized table |
| UV Protection | Yes |
| Load Capacity | 70-90 KGS/SQM |
Parameter
|
Item Name |
Multi-layers Vertical Grow Racks |
|
Application Scenario |
Hydroponics, Aeroponics, Soil |
|
Applicable Industries |
Farms, Manufacturing Plant, Indoor Farming, Vertical Farming |
|
Applicable Stage |
Seed Starting, BLOOM, VEG, Full growing stage |
|
Keywords |
Multi layer rolling bench, Ebb and Flow tables, Seedbed bench |
|
Feature |
Can be move and adjust the height, with tray |
|
Condition |
New |
|
Core Components |
Vertical Grow Racks, Grow Trays, LED Grow Lights, |
|
Supporting system |
Vertical Ventilation System, Drip Irrigation System, Control System |
|
Size |
Standard: 4x8x15ft Per Set, Customizable |
|
Material |
Iron, Galvanized Steel, Stainless Steel |
|
Material of Racks |
High Strength Steel with White Powder Coat |
|
Bearing Weight |
Beams support 2360 lbs. Uprights support up to 17600 lbs. |
|
Layers |
1-4 Layers Optional |
|
Grow Trays |
2.5mm-4.5mm ABS Plastic Optional, 4x8ft Standard Size, Customizable |
|
LED Grow Lights |
Many Models Available. Samsung & Osram Chips Available. Drivers Optional. |
|
Support Dimmer |
YES |
|
Vertical Ventilation System |
Airflow Up to 2206m²/h, Air Pressure Up to 1059PA |
|
Drip Irrigation Systems |
Five Channels for Water and Fertilizer Irrigation, 110V-380V,0.75KW*2. Built-in EC Senso & PH Sensor. Touth Screen or App Control. |
|
Warranty of core components |
5 years |
Vertical Growing Racks
Vertical Growing Racks are the most efficient indoor growing solution, it takes full advantage of free floor space, and can double your storage capacity while also keeping your plants safe.
● Custom designed to make the best use of available space.
● Move the rows effortlessly with mechanical-assist handles.
● Support different levels of plants, lights, fans, and irrigation systems, enabling the facility to dramatically increase its yields (and your profits).
